Cortizo is a leading company in Europe in the design and manufacture of aluminum systems with a wide range of operations (sliding, hinged, folding, etc...) and applications. Cortizo systems have high thermal and acoustic performance, as well as innovative minimalist designs that guarantee maximum luminosity, solutions for large dimensions, latest generation facades, etc....

Frameless Systems

The ultra-slim doors and windows systems guarantee maximum luminosity, solutions for large openings and state-of-the-art design. Besides the breath taking panoramic views, these solutions provide great thermal and acoustic performance.  With our wide variety of minimalist systems we are able to offer unlimited choices of design, operation, finishes, etc...

Technical Data

Maximum Dimensions and Weight (per sash)
Width(L)= 4000 mm

Height(H)= 4000 mm

Max Weight= 400 Kg / 800 Kg(M)

Energy Efficiency

Uw from 0,9 (W/m².K)

Accoustic Insulation

Max glazing: 54 mm
Max accoustic insulation: Rw=43 dB

Opening Possibilities

Sliding of 1, 2, 3, 4 and 6 sashes

press to zoom

press to zoom

press to zoom

press to zoom
1/4

Vision 1000

- Minimalist sliding system specially suitable for large dimensions (up to 4000 mm/sash of width or height) with the possibility to cover great openings with a glass surface of 94% with a visible section of just 25 mm and an outstanding thermal and acoustic performance

- It comes with the possibility of motorized opening for weights up to 700 kg, and manual opening for up to 400 kg. Additionally, it allows to place multipoint lock systems by operating rod, with or without key

- The rollers are placed in the frame, and the sashes include a stainless steel reinforced rolling area which makes the sliding movement smoother

- Possibility of corner sash encounters at 90º without needing a mullion

- The motorized version hides the sash completely within the frame in closed position

UltraSlim Frame Systems

The classic doors and windows systems provide extreme thermal and acoustic insulation. These solutions come with a larger and a more traditional sized frame. With our wide variety of classic systems we are able to offer unlimited choices of design, operation, finishes, etc...

Technical Data

Maximum Dimensions and Weight (per sash)
Width(L)= 3300 mm

Height(H)= 3300 mm

Max Weight= 400 Kg

Energy Efficiency

Uw from 0,9 (W/m².K)

Accoustic Insulation

Max glazing: 55 mm
Max accoustic insulation: Rw=43 dB

Opening Possibilities

Sliding of 2, 3, 4 and 6 sashes

press to zoom

press to zoom

press to zoom

press to zoom
1/4

Vision 2000

- Lift and slide door system that exhibits the best thermal insulation with a Uw from 0,9 Wm²K

- Possibility of two options for central sash encounter, 110 mm standard section and minimalist solution of only 50mm

- Possibility of large sash dimensions makes this system ideal for enclosing large spaces, at the same time that it provides maximum luminosity

- It is a robust system in appearance, but light at the same time, providing an ultra smooth opening action and perfect sash sliding over a stainless steel rail

Technical Data

Maximum Dimensions and Weight (per sash)
Width(L)= 2500 mm

Height(H)= 3000 mm

Max Weight= 280 Kg

Energy Efficiency

Uw from 1,1 (W/m².K)

Accoustic Insulation

Max glazing: 34 mm
Max accoustic insulation: Rw=40 dB

Opening Possibilities

Sliding of 2, 3, 4 and 6 sashes

press to zoom

press to zoom

press to zoom

press to zoom
1/4

Vision 2000

Thermally Broken

- System for sliding windows and doors with straight aesthetic


- Sashes of up to 280 kg weight allow maximum dimensions of 2500 (W) x 3000 (H) mm

- Central minimalist sash encounter of only 47 mm of visible section

- Stainless steel rails that allow for ultra smooth sliding

Official Fabricator

Panorama Windows is part of an exclusive network of certified fabricators and installers of Cortizo systems.



This network is integrated by a select group of installers whose technical quality in their work is manifest and has been shown repeatedly along their professional path.



The Cortizo Official Installers receive all the technical and professional support and training that they might need at any time in order to guarantee maximum quality in the manufacture, assembly and the installation process of the various types of Cortizo's building systems.

https://www.cortizo.com/en/paginas/localiza_tu_instalador

Cortizo Technology Center

Dedicated exclusively to research, development and innovation

Cortizo has a Technology Center with a multidisciplinary team of 52 people dedicated to developing new products and adapting existing ones to the construction and climatic realities of each area in which it is present.

Cortizo has an unlimited product offer backed by strict tests carried out at the Cortizo Technology Center and in laboratories of recognized international prestige.

  • Acoustic Test - Noise protection

  • Thermal Test - Energy Efficiency

  • AEV test - Air permeability, watertightness and wind resistance

  • Mechanical Test - Durability
