Minimalist Design Sliding Doors & Windows Systems

The ultra-slim doors and windows systems guarantee maximum luminosity, solutions for large openings and state-of-the-art design. Besides the breath taking panoramic views, these solutions provide great thermal and acoustic performance.  With our wide variety of minimalist systems we are able to offer unlimited choices of designs, operations, finishes, etc...

Screen%20Shot%202020-06-28%20at%207.49_e



Hi-Finity
High Insulation Thermally Broken

- Minimalist sliding system specially suitable for large dimensions (up to 3500 mm/sash of width or height) with the possibility to cover great openings with glass and a visible section of only 35 mm

- Outstanding thermal and acoustic performance

- It comes with the possibility of motorized opening for weights up to 750 kg

- Possibility of corner sash encounters at 90º without needing a mullion

- The motorized version hides the sash completely within the frame in closed position

Technical Data

Maximum Dimensions and Weight (per sash)
Width(L)= 3500 mm

Height(H)= 3500 mm

Max Weight= 750 Kg

Energy Efficiency

Uw from 1,4 (W/m².K)

Accoustic Insulation

Max glazing: 54 mm
Max accoustic insulation: Rw=43 dB

Opening Possibilities

Sliding of 1, 2, 3, 4 and 6 sashes

press to zoom

press to zoom

press to zoom

press to zoom
1/4
Villa in Cannes.jpg



Cor Vision Plus
High Insulation Thermally Broken

- Minimalist sliding system specially suitable for large dimensions (up to 4000 mm/sash of width or height) with the possibility to cover great openings with a glass surface of 94% and a visible section of just 25 mm and an outstanding thermal and acoustic performance

- It comes with the possibility of motorized opening for weights up to 700 kg, and manual opening for up to 400 kg. Additionally, it allows to place multipoint lock systems on the sides or interlocks, with or without key

- The rollers are placed in the frame, and the sashes include a stainless steel reinforced rolling area which makes the sliding movement smoother

- Possibility of corner sash encounters at 90º without needing a mullion

Technical Data

Maximum Dimensions and Weight (per sash)
Width(L)= 4000 mm

Height(H)= 4000 mm

Max Weight= 400 Kg / 800 Kg(M)

Energy Efficiency

Uw from 0,9 (W/m².K)

Accoustic Insulation

Max glazing: 54 mm
Max accoustic insulation: Rw=43 dB

Opening Possibilities

Sliding of 1, 2, 3, 4 and 6 sashes

press to zoom

press to zoom

press to zoom

press to zoom
1/4





Cor Vision

Thermally Broken

- Minimalist sliding system with a visible section of only 20 mm


- Possible to cover great openings with a maximum surface glazing area

- Allows to place multipoint lock systems by operating rod, with or without key

- Possibility of embedding the bottom, top and lateral frames within the wall

- Possibility of corner sash encounters at 90º without needing a mullion

- Possibility of pocket and galandage systems

Technical Data

Maximum Dimensions and Weight (per sash)
Width(L)= 2500 mm

Height(H)= 3000 mm

Max Weight= 320 Kg

Energy Efficiency

Uw from 1,3 (W/m².K)

Accoustic Insulation

Max glazing: 30 mm
Max accoustic insulation: Rw=41 dB

Opening Possibilities

Sliding of 1, 2, 3, 4 and 6 sashes

press to zoom

press to zoom

press to zoom

press to zoom
1/4
Screen Shot 2020-06-26 at 10.35.33 PM.pn



SlimPatio 68
Thermally Broken

- Minimalist sliding system with a visible width meeting section of only 34 mm


- Possible to cover great openings with a maximum surface glazing area

- Possibility of embedding the bottom, top and lateral frames within the wall

- Possibility of corner sash encounters at 90º without needing a mullion

- Possibility of pocket and galandage systems

Technical Data

Maximum Dimensions and Weight (per sash)
Width(L)= 2600 mm

Height(H)= 2700 mm

Max Weight= 320 Kg

Energy Efficiency

Uw from 2,4 (W/m².K)

Accoustic Insulation

Max glazing: 36 mm
Max accoustic insulation: Rw=40 dB

Opening Possibilities

Sliding of 1, 2, 3, 4 and 6 sashes

press to zoom

press to zoom

press to zoom

press to zoom
1/5

Classic Design Sliding Doors & Windows Systems

The classic doors and windows systems provide extreme thermal and acoustic insulation. These solutions come with a larger and a more traditional sized frame. With our wide variety of classic systems we are able to offer unlimited choices of design, operation, finishes, etc...



4600 Lift & Slide
High Insulation Thermally Broken

- Lift and slide door system that exhibits the best thermal insulation with a Uw from 0,9 Wm²K

- Possibility of two options for central sash encounter, 110 mm standard section and minimalist solution of only 50mm

- Possibility of large sash dimensions makes this system ideal for enclosing large spaces, at the same time that it provides maximum luminosity

- It is a robust system in appearance, but light at the same time, providing an ultra smooth opening action and perfect sash sliding over a stainless steel rail

Technical Data

Maximum Dimensions and Weight (per sash)
Width(L)= 3300 mm

Height(H)= 3300 mm

Max Weight= 400 Kg

Energy Efficiency

Uw from 0,9 (W/m².K)

Accoustic Insulation

Max glazing: 55 mm
Max accoustic insulation: Rw=43 dB

Opening Possibilities

Sliding of 2, 3, 4 and 6 sashes

press to zoom

press to zoom

press to zoom

press to zoom
1/4
Screen%20Shot%202020-06-26%20at%2010.38_



CP 130 Lift & Slide
High Insulation Thermally Broken

- Concept Patio® 130 is a highly insulated lift and slide system, which meets the highest requirements with regard to insulation, stability and safety


- This robust system allows the construction of large and stable sliding windows and doors with a vent weight up to 350 kg allowing maximum dimensions of 2700 (W) x 2700 (H) mm

- It offers an aesthetical slimline middle section of only 69 mm

- This sliding system can comply with burglar resistance class 2, offering a safe and secure solution

Technical Data

Maximum Dimensions and Weight (per sash)
Width(L)= 2700 mm

Height(H)= 2700 mm

Max Weight= 350 Kg

Energy Efficiency

Uw from 2,3 (W/m².K)

Accoustic Insulation

Max glazing: 43 mm
Max accoustic insulation: Rw=40 dB

Opening Possibilities

Sliding of 2, 3, 4 and 6 sashes

press to zoom

press to zoom

press to zoom

press to zoom
1/6





CP 130

Thermally Broken

- Concept Patio® 130 is a highly insulated sliding system, which meets the highest requirements with regard to insulation, stability and safety


- This robust system allows the construction of large and stable sliding windows and doors with a vent weight up to 300 kg allowing maximum dimensions of 2600 (W) x 2700 (H) mm

- It offers an aesthetical slimline middle section of only 69 mm

- This sliding system can comply with burglar resistance class 2, offering a safe and secure solution

Technical Data

Maximum Dimensions and Weight (per sash)
Width(L)= 2600 mm

Height(H)= 2700 mm

Max Weight= 300 Kg

Energy Efficiency

Uw from 2,3 (W/m².K)

Accoustic Insulation

Max glazing: 43 mm
Max accoustic insulation: Rw=37 dB

Opening Possibilities

Sliding of 2, 3, 4 and 6 sashes

press to zoom

press to zoom

press to zoom

press to zoom
1/5



4700
Thermally Broken

- System for sliding windows and doors with straight aesthetic


- Sashes of up to 280 kg weight allow maximum dimensions of 2500 (W) x 3000 (H) mm

- Central minimalist sash encounter of only 47 mm of visible section

- Stainless steel rails that allow for ultra smooth sliding

Technical Data

Maximum Dimensions and Weight (per sash)
Width(L)= 2500 mm

Height(H)= 3000 mm

Max Weight= 280 Kg

Energy Efficiency

Uw from 1,1 (W/m².K)

Accoustic Insulation

Max glazing: 34 mm
Max accoustic insulation: Rw=40 dB

Opening Possibilities

Sliding of 2, 3, 4 and 6 sashes

press to zoom

press to zoom

press to zoom

press to zoom
1/4





4900

High Insulation Thermally Broken

- Sliding window and door system with straight aesthetic which has a slim interlock of just 35 mm

- It allows to have glass thicknesses of up to 36 mm, increasing the thermal and acoustic performance

- Its sashes of up to 240 kg can reach the dimensions of 2200 (W) x 2600 (H) mm

Technical Data

Maximum Dimensions and Weight (per sash)
Width(L)= 2200 mm

Height(H)= 2600 mm

Max Weight= 240 Kg

Energy Efficiency

Uw from 1,2 (W/m².K)

Accoustic Insulation

Max glazing: 36 mm
Max accoustic insulation: Rw=40 dB

Opening Possibilities

Sliding of 2, 3, 4 and 6 sashes

press to zoom

press to zoom

press to zoom

press to zoom
1/3
